Genie telescopic S-booms have working heights of 14.20 meters to 40.15 meters and a horizontal reach of between 9.65 meters and 24.38 meters. Compared with different other aerial work platforms, telescoping booms have a a range of horizontal reach that is much greater. Genie telescopic booms are designed with consideration to being able to access confined places during construction and industrial applications. They are also recognized for their ability to rapidly maneuver through a job site with great drive speed and traction. The platform hydraulically turns 160�° and can stay level through the whole range. Front-entry platforms come with 227 kilogram to 272 kilogram capacity for operators and tools and are available from 1.83 meters to 2.44 meters. Continuous, 360�° rotating turntables provide operators easy, quick positioning.
The Z-135/70 model has a telescoping jib, called the Jib-Extend, that goes from 3.66 meters to 6.1 meters. This particular model can also reach 110�° vertically to give the user the ability to reach jobs that were previously unreachable by conventional jibs. A secondary reverse-articulating boom on the Z-80/60 model gives the user 8.83 meters of over and up reach. This feature allows over and up reaching tasks to be completed with zero front arm swing.
The Fast Mast System built by Genie allows for time to be saved when both secondary and primary booms platform needs to either be lowered or lifted without needing to lower the secondary boom. The Fast Mast system allows both booms to be raised fully simultaneously. Both of these features of the Genie Fast Mast system reduces the time needed for users to descend and ascend, increasing productivity and effectiveness.
